These deluxe quality Hurricane Series Aluminum Flagpoles are designed to meet and withstand the highest known wind speed loading and can be used in most locations worldwide. The Hurricane Series Flagpoles have an Increased Wall Thickness and or Butt Diameter which makes these poles the best choice for high wind locations. If you don't see the specification you need please call 800-580-0009 x204. Construction is from the finest quality Alcoa 6063-T6 seamless extruded aluminum. The exterior surface is given a special machine-sanded, fine grain grit satin finish to ensure the longest maintenance-free life possible.
Call and see about local Flagpole installation.
Item # (Scroll on Mobile) | FW324117 | FW324118 | FW324119 | FW324120 | FW324121 |
---|---|---|---|---|---|
ABOVE GROUND HEIGHT (FT) | 25 | 30 | 35 | 40 | 50 |
TOTAL LENGTH (FT) | 27 | 33 | 38.5 | 44 | 55 |
BUTT DIAMETER (IN) | 6 | 6 | 8 | 8 | 10 |
TOP DIAMETER (IN) | 3.5 | 3.5 | 3.5 | 3.5 | 4 |
WALL (IN) | .250 | .250 | .250 | .250 | .312 |
SECT/WT* [See Notes] | 1/239 | 2/283 | 2/382 | 2/421 | 3/799 |
UN-FLAGGED MAX WIND SPEED | 255 MPH | 241 MPH | 255 MPH | 231 MPH | 230 MPH |
FLAGGED MAX WIND SPEED | 150+ MPH | 150+ MPH | 150 MPH | 150 MPH | 150 MPH |
ORDER |
$3960.00 |
$5420.00 |
$6080.00 |
$7030.00 |
$13180.00 |
For a double cleat, double halyard system, add $46 to above price. Make a note in the Comments section in the shopping cart and price will be adjusted accordingly.
*Freight charges will be added to your order. See additional ordering notes here.
Call for a quote if needed. 1-800-580-0009 or email.
Freight quotes are an estimate only. Actual shipping charges may increase due to any accessorial charges that may occur including: notification calls, limited access charges, over-dimensions fees, residential fees and fuel surcharges.
These deluxe internal halyard flagpoles contain a winch mounted inside the flagpole shaft, operable only with a removable crank handle. As the stainless steel cable unwinds from the winch, it passes up through the inside of the flagpole shaft, over the truck sheave to the outside of the shaft, where the retaining ring provides a sliding anchor. A counterweight, heavily coated with neoprene, attached to the retaining ring, allows the halyard to be lowered for fastening or removing the flag. The halyard is then raised completely out of reach of vandals. The improved winch is gearless and self-locking at any point, eliminating the need for a separate brake. This direct drive winch provides rapid raising and lowering of the flag with little effort. This new, improved design does not require any welding, thus avoiding discoloration when an anodized finished is desired. No monthly lubrication is needed and this winch system is easily adaptable to existing on-site flagpoles.
Item # (Scroll on Mobile) | FW324137 | FW324138 | FW324139 | FW324140 | FW324141 |
---|---|---|---|---|---|
ABOVE GROUND HEIGHT (FT) | 25 | 30 | 35 | 40 | 50 |
BUTT DIAMETER (IN) | 6 | 6 | 8 | 8 | 10 |
TOP DIAMETER (IN) | 3.5 | 3.5 | 3.5 | 3.5 | 4 |
WALL (IN) | .250 | .250 | .250 | .250 | .312 |
SECT/WT* [See Notes] | 1/239 | 2/283 | 2/382 | 2/421 | 3/799 |
UN-FLAGGED MAX WIND SPEED | 255 MPH | 241 MPH | 255 MPH | 231 MPH | 230 MPH |
FLAGGED MAX WIND SPEED | 150+ MPH | 150+ MPH | 150 MPH | 150 MPH | 150 MPH |
ORDER |
$6480.00 |
$8080.00 |
$8830.00 |
$10070.00 |
$16490.00 |
Freight: Due to carrier limitation commercial flagpoles 25' and longer may be shipped in two sections. Freight quotes are an estimate only. Actual shipping charges may increase due to any accessorial charges that may occur including: notification calls, limited access charges, over dimensions fees, residential fees and fuel surcharges.
Sales Tax: Sales tax will be charged for aluminum flagpoles delivered to these states. IL 7%, MD 6%, WI 5.6%, FL 7.5%.
Warning: The flagpole shaft will stain if allowed to remain in contact with wet or damp wrapping. If pole is to be stored outside please store unwrapped.
Finishes: All poles can be finished by satin ground, anodized or thermo set powder paint. Call 800-580-0009 ext204 for details and cost.
Other Poles Available: Nautical (single and double mast), Counter Balance (tilting), bronze/stainless steel, vertical wall mount, and outrigger. Please call 800-580-0009 x204
